Disc Brake Lathe Machine

Disc Lathe:

1. Maximum brake disc thickness: 40mm
2. Adjustment knob accuracy: 0.005mm
3. Feed rate: 8.5mm/min
4. Electrical specifications: 220V / 110V
5. Net weight: 7.3kg

Drive Unit:

1. Working height min / max: 1 / 1.25m
2. Drive speed: 98rpm
3. Electrical specifications: 220V / 110V
4. Weight: 85kg
5. Ambient temperature range: -5°C to 35°C
6. Turning accuracy: ≤ 0.005mm
7. Brake disc runout: ≤ 0.005mm
8. Brake disc thickness variation: 0.005 – 0.01mm
9. Brake disc surface roughness: Ra 1.5 – 2.0um

Features:

• Upgraded and remodeled from customer-oriented perspectives to enable easier and safer car brake disc resurfacing.
• Resurfacing articularly improves the performance of the brake disc and shortens the braking distance to guarantee safer operations.
• Try operating it on various vehicle types.
